IN-CEILING/WALL-MOUNT SPEAKERS

I N S T A L L A T I O N / O W N E R S' M A N U A L

MODEL IC5 / IC6 (NON-AMPLIFIED SPEAKERS)

SPEAKER SPECIFICATIONS:

MODEL IC5

MODEL IC6

DESCRIPTION:

5.25" 2-way in-ceiling speaker

6.5" 2-way in-ceiling speaker

COVERED OUTDOOR:

Yes

IMPEDANCE:

8 ohm

SENSITIVITY (1W/1M):

86dB 1w/M

87dB 1w/M

DISPERSION:

140 deg

MAX POWER:

40 watts

50 watts

NOMINAL POWER:

20 watts

25 watts

FREQUENCY RESPONSE:

90Hz - 20KHz

65Hz-20KHz

CROSSOVER:

6 dB/Octave

WOOFER SIZE:

5.25"

6.5"

WOOFER MATERIAL:

Paper coated woofer with foam surround

TWEETER SIZE:

0.5" (13mm) balance tweeter

TWEETER MATERIAL:

Ferrite magnet with Mylar diaphragm
material

GRILL MATERIAL:

Aluminum

DIMENSIONS:

7.95" (202mm) Dia x 2.75" (70mm) mounting
depth

8.78" (223mm) Dia x 3.35" (85mm)
mounting depth

CUT OUT SIZE:

6.61" (168mm)

7.68" (195mm)

WEIGHT:

2.17 lbs (985 gms)

2.51 lbs. (1140 gms)

MOUNTING HARDWARE:

Clamps - 4 each

PAINTABLE: Yes

Yes

INSTALLATION:

Speaker Placement

Before installing your OWI speakers, consider the placement carefully, taking into effect the location of
electrical, plumbing and other fixtures.

Placement in Ceiling

OWI speakers should be ideally located above the primary listening area.

Placement in Wall

Optimum sound will be achieved when your OWI speakers are installed at ear level or slightly higher and the
listening area is no closer to the speakers than the distance between the speakers themselves.

Mounting your OWI Speakers

Determine the best area to mount your OWI speakers. It will be necessary to run your speaker wires to that
