OWI IC6-DVC - Manual

ARCHITECTS AND ENGINEERS
SPECIFICATIONS / TECHNICAL DATA
GENERAL SPECIFICATIONS
MODEL NUMBER: IC6-DVC
DESCRIPTION: 6.5" Dual Voice Coil
Twin Tweeters
COVERED OUTDOOR: No
IMPEDANCE: 8 Ohms
SENSITIVITY (1W/1M): 87 dB
DISPERSION: 120
o
MAX POWER: 60 Watts
NOMINAL POWER: 30 Watts
FREQUENCY RESPONSE: 60 Hz - 20 kHz
CROSSOVER: 2.5 kHz
WOOFER SIZE: 6.5"
WOOFER MATERIAL: Polycarbonate
Rubber Surround
TWEETER SIZE: Twin 0.5" - 2 Each
TWEETER MATERIAL: Hard Dome
GRILL MATERIAL: Aluminum
DIMENSIONS: 9 1/8 " Diameter x 4" Height
CUT OUT SIZE: 7 3/4 " Diameter
WEIGHT: 3.75 lbs.
MOUNTING HARDWARE: Kwik Klamps
PAINTABLE: Yes
IN CEILING SPEAKER
6.5" DUAL VOICE COIL, 8 OHMS
OWI Incorporated
17141 Kingsview Avenue, Carson, CA 90746 USA
Tel: 310.515.1900
Toll Free: 800.638.1694
Fax: 310.515.1606
Web: www.owi-inc.com
E-mail: [email protected]
®
