31.
Front Panel
DS1000B / DS1500B / DS2000B / DS3000B
A) Function
B) Enter
C) On / Off
C B A
FUNC ENTER ON/OFF
ON ON-LINE ON-BAT BYPASS FAULT
Rear Panel
DS1000B / DS1500B
100V/110V/120V
220V/230V/240V
RS232
EPO
Data Line
Protection
Circuit Breaker
Input
USB
Extended Battery
Connector
Battery Backup Outlets
EPO
Data Line
Protection
RS232
Circuit Breaker
Input
Battery Backup Outlets
Extended Battery
Connector
USB
DS2000B / DS3000B
RS232
EPO
Data Line Protection
Battery Backup Outlets
Circuit Breakers
Extended Battery Connector
USB
RS232
EPO
Data Line Protection
Circuit Breaker
Input
USB
Extended Battery Connector
Battery Backup Outlets
Circuit Breakers
100V/110V/120V
220V/230V/240V
SNMP Card Slot SNMP Card Slot
SNMP Card Slot
SNMP Card Slot
