EN
RAINFALL
to view the recorded rainfall of the current hour or
last 24 hours:
. Press SELECt to navigate to the UVI / Barometer /
Rainfall Area. will show next to the Area.
2. Press ModE repeatedly to select Rainfall display.
3. Press MAX / MIN repeatedly to toggle between
current hour or past 24 hour rainfall.
BACkLIGHt
Press LIGHt to activate the backlight for 5 seconds.
RESEt
Press RESEt to return to the default settings.
SPECIFICAtIoNS
BASE StAtIoN
Dimensions
(L x W x H) 80mm x 0mm x 47mm
(7. x 4.3 x .9 inches)
Weight 286g (0 ounces) without battery
Battery 6V adaptor; 4 x UM-3 (AA) .5V
USB CoMMUNICAtIoNS HUB
Dimensions
(L x W x H) 68 x 46 x 36 mm
(2.7 x .8 x 5.4 inches)
Weight 02 g (3.6 oz)
INdooR BARoMEtER
Barometer unit mb, inHg and mmHg
Measuring range 700 – 050mb/hPa
Accuracy
+/- 0 mb/hPa
Altitude setting
Sea level
User setting for compensation
Weather display
Sunny, Partly Cloudy, Cloudy, Rainy
and Snowy
Memory
Historical data and bar chart for last
24hrs
INdooR tEMPERAtURE
Temp. unit °C / °F
Displayed range 0°C to 50°C (32°F to 22°F)
Operating range -30°C to 60°C (-4°F to 40°F)
Accuracy
0°C - 40°C: +/- °C (+/- 2.0°F)
40°C - 50°C: +/- 2°C (+/- 4.0°F)
Memory
Current, Min and Max temp.
Dew Point w/ Min and Max
INdooR RELAtIVE HUMIdItY
Displayed range 2% to 98%
Operating range 25% to 90%
Accuracy
25% - 40%: +/- 7%
40% - 80%: +/- 5%
80% - 90%: +/- 7%
Memory Current, Min and Max
RAdIo-CoNtRoLLEd / AtoMIC CLoCk
Synchronization Auto or disabled
Clock display HH:MM:SS
Hour format 2hr AM/PM or 24hr
Calendar DD/MM or MM/DD
Weekday in 6
languages
(E, D, F, I, S, R)
REMotE WINd SENSoR UNIt
Dimensions
(L x W x H) 78 x 76 x 24 mm
(7 x 3 x 8.4 inches)
Weight 00 g (3.53 ounces) without battery
Wind speed unit m/s, kph, mph, knots
Speed accuracy
2 m/s ~ 0 m/s (+/- 3 m/s)
0 m/s ~ 56 m/s (+/- 0%)
Direction
accuracy
6 positions
Transmission of
wind speed
signal
Approx. every 56 seconds
Memory Max wind speed
Battery 2 x UM-3 (AA) .5V batteries
oUtdooR tEMPERAtURE / HUMIdItY UNIt
Dimensions
(L x W x H) 5 x 87 x 8 mm
(4.5 x 3.4 x 4.6 inches)
Weight 30 g (4.59 oz) without battery
Humidity range 5% to 95%
Humidity
accuracy
25% - 40%: +/- 7%
40% - 80%: +/- 5%
80% - 90%: +/- 7%
Temp. unit °C / °F
Temperature
outdoor range
-30°C to 60°C (-22°F to 40°F)
Temperature
accuracy
-20°C to 0°C:
+/- 2.0°C (+/- 4.0°F)
0°C to 40°C:
+/- .0°C (+/- 2.0°F)
40°C to 50°C:
+/- 2.0°C (+/- 4.0°F)
50°C to 60°C:
+/- 3.0°C (+/- 6.0°F)
RF frequency 433 MHz
Range
Up to 00 meters (328 feet) with no
obstructions
Transmission Approx. every 02 seconds
Channel no. 3
Batteries 2 x UM-4 (AAA) .5V
REMotE RAIN GAUGE
Dimensions
(L x W x H) 4 x 4 x 45 mm
(4.5 x 4.5 x 5.7 inches)
Weight 24 g (8.5 oz) without battery
Rainfall unit Mm and in
Range 0 mm – 9999 mm
Accuracy
< 5 mm: +/- mm
5 mm to 9999 mm: +/- 7%
Memory
Past 24hrs, hourly from last memory
reset
Battery 2 x UM-3 (AA) .5V
