Asus ROG Xonar Phoebus - Manual (Page 33)

33 ASUS Xonar Phoebus
6.2.8 Flex Bass II
Function Introduction
No Item Description
1 Flex Bass II enable/
disable switch
Click on this check box to enable / disable Flex Bass II.
2 Bass Level The bass level range is from -2 to 2dB.
3 Speaker Size Small Speaker w/o bass
When the speaker size is set to small, you can hear the
sound resonance more obvious and reverberation from
subwoofer.
4 Speaker Diagram You can also check the speaker size from this home theater
diagram.
5 Cut Off Frequency The cut off range of low frequency is from 50Hz to 250Hz.
This function allows you to increase / decrease the LFE strength. This function
would cut the low frequency band (50~250Hz) of stereo music content (eg.
Mp3,WMA, CD Audio) and transfer to subwoofer or each speaker.
1
3
2
5
4
