The 2GXM2 has integrated management, eliminating the cost
and space required for external management hardware.
The

iConverter

management system provides comprehensive

remote configuration and performance monitoring.

iConverter

management reduces operational expenditures by keeping truck
rolls to a minimum through remote provisioning, unidirectional
fault detection, trap notification and loopback capabilities.

iConverter

management is available out-of-band via IP-Less

protocol using the 802.3ah OAM channel or Omnitron’s Secure
OAM channel, or in-band using SNMP or Telnet.

Management is accessed via Omnitron’s

NetOutlook

®

SNMP

Network Management Software with an intuitive Graphical User
Interface, or third party SNMP software. Telnet and CLI
management interfaces are also supported, and utilize an easy
to use, menu-driven interface. The CLI interface is accessed via
a Serial Console Port, that provides local configuration and allows
for firmware updates. Additionally, the port can be connected to
a serial modem to provide an alternative remote management path.

IP-Based Management
The 2GXM2 can be managed through IP protocols, SNMPv1,
SNMPv2c, SNMPv3 and Telnet. The IP address of the 2GXM2
can be user-defined or resolved through the DHCP host on the
network. The IP protocols for management access can be
enabled or disabled individually or as a group. Access to the
management is protected by password authentication. SMNPv3
strengthens secure access to devices by a combination of
authenticating and encrypting packets over the network.
Management VLAN can also be defined to separate
management traffic from customer traffic.

802.3ah and Secure OAM Management Channels
When utilizing a Remote OAM management channel (Secure
IP-less or 802.3ah), the NID at the Customer Premises is
securely managed by its fiber link partner located at the Central
Office or Point of Presence. The management network IP
address is not available to the customer network and is isolated
by the

iConverter

Network Management Module (NMM) in the

19-Module Chassis at the Central Office.

A management processor on the

iConverter

2GXM2 in the

19-Module Chassis isolates the encrypted management data
from the customer data and communicates with the NMM via a
separate management backplane bus. Management traffic on
the user data lines is IP-less and carried on a securely encrypted
data channel to protect the management from unauthorized
access. The chassis at the Central Office requires only a single
IP address to manage itself and all of the connected remote
chassis managed by the Remote OAM channel. This is the
ideal configuration for networks that separate secure
management traffic from the service (customer) traffic on different
networks, or when management IP addresses are at a premium.

Page 3

Description

1000BASE-X to 1000BASE-X Fiber

Media Converter and Network Interface Device

Protocols

1000BASE-X

with 10,240 bytes max. frame size

Fiber Cables

Multimode: 50/125, 62.5/125, 100/140µm

Single-mode: 9/125µm

Serial Cable

RS-232, 22 to 24 AWG, 12 to 50 pF/ft.

Fiber Connectors

Small Form Pluggable (SFP)

Serial Connector

Mini DIN-6 female,

mini DIN-6 male to DB-9 female adapter included

Controls

DIP-Switches and LEDs

DC Power

Plug-In Module: 1.1A @ 3.3VDC

Standalone: 8-15VDC,

0.5A @ 9VDC

DC Power Connector

Plug-In: Power supplied by backplane

Standalone: 2.5mm Barrel Connector or

Field-wireable Terminal Connector

AC Power Adapter
[US]

Plug-In Module: N/A

Standalone: 100-120VAC/60Hz

0.05A @ 120VAC

AC Power Adapter
[Universal]

Plug-In Module: N/A

Standalone: 100-240VAC/50-60Hz

0.05A @ 120VAC

Dimensions

Plug-In Module: W:0.85" x D:4.5" x H:2.8"

Standalone: W:3.1" x D:4.8" x H:1.0"

Wallmount: W:3.8" x D:4.8" x H:1.0"

Weight
without power adapter

Plug-In Module: 8oz.

Standalone: 1 lb.

Weight
with power adapter

Plug-In Module: N/A

Standalone: 1.5 lb.

Compliance

UL, CE, FCC Class A, MEF 9, MEF 14

IP-Based Management

Telnet; SNMPv1, SNMPv2c, SNMPv3

Temperature

Standard Operating: 0 to 50º C

Wide Operating: -40 to 60º C

Extended Operating: -40 to 75º C

Storage: -40 to 80º C

Humidity

5% to 95% (non-condensing)

Altitude

-100m to 4000m (Operational)

MTBF (Hours)

Plug-In Module: 540,000

Standalone without Power Adapter: 540,000

Standalone With Power Adapter: 250,000
