6.0:
Specification (continued)
PSIM-AC PSIM-DC PSIM-5V
Input
Line Voltage
10 to 30 Vdc.
Current 1.1 A @ 12 Vdc; 0.5 A @ 24 Vdc (nominal).
Connection see note 3 5m flying lead (Red = positive, White = negative)
Isolation >500 VDC input/output
Protection Input fuse and filter (not user replaceable)
Over voltage and under voltage shut down
Reverse connection
DC Output
Output Voltage
5.1 Vdc. Nominal
Output Current 1.8 A max. (i.e. 31 Orbit Modules)
Output Regulation 3% (Line / Load)
Transient Response 200us to 1% (FL to 1/2L)
Ripple and Noise < 1% p-p
Efficiency 80% to 86% typical
Protection see note 2
Thermal Derating The output current shall be derated from 40 °C
to 60 °C by 50%. (ie. Max. output at 60 °C
is 0.9A or 15 Orbit Modules.)
All specifications are for a PSIM supplying a full network of probes.
PSIM-DC
LDN-PS
14
M-3340/1206
