SECTION 7: F

LUE

I

NSTALLATION

15 of 42

Figure 9: Vertical and Horizontal Flue Termination - Type C

12

C

32

& C

62

Appliances

Wall

Plate

Wall

Terminal

Flue

Roof Terminal

Flue

Air Intake

Air Intake

Manifold

Manifold

Vertical

Option

Plastic Cup

Masterflash

Horizontal

Option

Remove Internal

Wire Mesh

Remove Internal

Wire Mesh
