GA-MA790FXT-UD5P Motherboard - 52 -
Onboard Audio Function
Enables or disables the onboard audio function. (Default: Enabled)
If you wish to install a 3rd party add-in audio card instead of using the onboard audio, set this item
to Disabled.
Onboard LAN device
CMOS Setup Utility-Copyright (C) 1984-2009 Award Software
Onboard LAN device
Item Help
Menu Level
Onboard LAN1 Function [Enabled]
Onboard LAN1 Boot ROM [Disabled]
 SMART LAN1
[Press Enter]
Onboard LAN2 Function [Enabled]
Onboard LAN2 Boot ROM [Disabled]
 SMART LAN2 [Press Enter]
: Move
Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Onboard LAN1/2 Function (LAN1/2 Port)
Enables or disables the onboard LAN function. (Default: Enabled)
If you wish to install a 3rd party add-in network card instead of using the onboard LAN, set this item
to Disabled.
Onboard LAN1/2 Boot ROM (LAN1/2 Port)
Allows you to decide whether to activate the boot ROM integrated with the onboard LAN chip.
(Default: Disabled)
SMART LAN1/2 (LAN Cable Diagnostic Function)
CMOS Setup Utility-Copyright (C) 1984-2009 Award Software
SMART LAN
Item Help
Menu Level
Start detecting at Port.....
Part1-2 Status =
Open / Length = 0 m
Part3-6 Status = Open / Length = 0 m
Part4-5 Status = Open / Length = 0 m
Part7-8 Status = Open / Length = 0 m
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
This motherboard incorporates cable diagnostic feature designed to detect the status of the attached LAN
cable. This feature will detect cabling issue and report the approximate distance to the fault or short.
Refer to the following information for diagnosing your LAN cable:
When No LAN Cable Is Attached...
If no LAN cable is attached to the motherboard, the Status fields of all four pairs of wires will show
Open and the Length fields show 0m, as shown in the figure above.
