Page 9
Section 1 Configuration
CAUTION
Use an NQPACK100SE socket (manufactured by
Tokyo Eletech Corporation) for the TFP-100G package
IC socket on the user system.
Figure 1 shows the configuration of the HS3854ECN61H user system interface cable for the
TFP-100G package.
Figure 1 HS3854ECN61H User System Interface Cable
1
