www.RuggedCom.com 8 RuggedSwitch ® RS940G
RuggedSwitch
®
RS940G
8-Port Managed Gigabit Ethernet Switch, 128-bit Encryption
Order Codes
Base unit includes 6 - 10/100/1000 BaseTX ports
PS: Power Supply
„ „ 24 = 24 VDC (10-36 VDC)
„ „ 48 = 48 VDC (36-72 VDC)
„ „ HI = 88-300VDC or 85-264VAC
M: Mounting Option
„ „ D = DIN Rail
„ „ P = Panel Mount
„ „ N = None
P7P8: Transceiver Options:
„ „ XXXX = None
„ „ 2TX = Dual 10/100/1000TX RJ45
„ „ 2SFP = Dual 1000X SFP (Mini-GBIC). Order SFP Optics Separately.
„ „ 2LCMM = Dual 1000SX Multimode LC 850nm 500m
„ „ 2LC10 = Dual 1000LX Singlemode LC 1310nm 10km
„ „ 2LC25 = Dual 1000LX Singlemode LC 1310nm 25km
„ „ 2SC10 = Dual 1000LX Singlemode SC 1310nm 10km
„ „ 2SC25 = Dual 1000LX Singlemode SC 1310nm 25km
SFP (Mini-GBIC) Transceiver Options (1) (2):
„ „ 25-10-0111 = 1000SX SFP, Multimode, LC, 850nm, 500m (1) (3)
„ „ 25-10-0100 = 1000LX SFP, Singlemode, LC, 1310nm, 10 km (1)
„ „ 25-10-0101 = 1000LX SFP, Singlemode, LC, 1310nm, 25 km (1)
„ „ 25-10-0109 = 1000LX SFP, Singlemode, LC, 1550nm, 70 km (1) (3)
MOD: Manufacturing Modifications
„ „ XX = None
„ „ C01 = Conformal Coating
Notes:
1 Distance ratings are typical but will depend on type of cabling, number of connectors and splices.
2 Should you not find an appropriate fiber optic option listed here, please consult RuggedCom for other options.
3 These transceivers have an operating temperature range of -20 to +85°C. All other transceivers have an operating temperature range of -40° to +85°C.
RS940G - ____ - ___- _____ - _____
PS M P7P8 MOD
