13
Mounting options
Preparing the mounting holes
Mounting platform
Mounting platform
FORWARD
FORWARD
1
2
D8859_1
A
Mounting platform
D8860_1
IMPORTANT
Ensure mounting
platform is
adequately robust
for this
installation.
FORW
ARD
1
2
1. Tape template to mounting
platform.
2. Using template, drill 10 mm
diameter hole in 4 positions.
Dr
ill 4 holes
, 10 mm diameter
(18'' and 24'' Radomes)
141.5 mm
27.5 mm
233 mm
18'' or 24'' NGS Radome
Mounting T
emplate
Center Line of Radome
3026-136-A
Artwork Number 3032-
866-
A
Center Line of Radome
Fo
rw
ard
