Raypak 240692 User Manual
Page 3
TABLE OF CONTENTS
Contents
Page
Basics
4
Important Safety Instructions
4
Introduction
5
Concept of Operation
5
Optional Configurations
5
Control Features
6
Installation and Mounting
7
Mechanical Installation
7
Electrical Installation
7
Wiring: Power to Controller
8
Air Temperature Sensor
9
Water Temperature Sensor Installation
10
Hydronic Installations
10
Domestic Hot Water Installations
11
Pool Heating Installations
12
Field Wiring
13
Power Test
14
Control Familiarization
15
Sequence of Operation
16
Manual Override
16
Indicator Lights
18
Control Functions
19
Reset Ratio Chart
19
Circuit Board
23
Interior Jumper & Switches
24
Optional Controls
26
Replacement Parts List
27
System Start-Up Settings
28
Troubleshooting Guide
29
Warranty
30
