6 Runco CP-42HD/CP-52HD Owner ’s Operating Manual
Controls and Functions
1. HANDLES
Always use the handles when carrying the display. DO NOT touch or
hold the screen face.
2. KEYPAD
You can use the keypad instead of the remote control unit to operate the on-
screen display (OSD) controls. The keypad operates as follows:
VOLUME DOWN / MENU LEFT
Use this button to increase sound volume. When a menu is
visible on-screen, this button operates identically to the Left Key
on the Climate Series remote control unit.
VOLUME UP / MENU RIGHT
Use this button to increase sound volume. When a menu is
visible on-screen, this button operates identically to the Right
Key on the Climate Series remote control unit.
CHANNEL DOWN / MENU DOWN
Use this button to adjust the channel up. When a menu is
visible on-screen, this button operates identically to the Down
Key on the Climate Series remote control unit.
CHANNEL UP / MENU UP
Use this button to adjust the channel down. When a menu is
visible on-screen, this button operates identically to the Up Key
on the Climate Series remote control unit.
SOURCE
To select a source, press the SOURCE button repeatedly (with
no menu available on-screen).
MENU
Press this button to access the on-screen display (OSD), or to
exit the current menu and return to the previous one.
POWER
Use this button to turn the unit on and off.
3. IR SENSOR / STATUS LED
Infrared (IR) Sensor that receives signals from the remote control. Status
LED lights red to indicate that the Climate Series LCD is in standby mode or
if the main power switch is set to off; green during normal operation.
4. INTAKE VENTS
Internal fans draw cool air into the monitor through these vents.
5. BACK PANEL INPUT/OUTPUT COVER
Input/Output connections are recessed in the back of the monitor and have a
cover engineered to keep connections dry.
6. EXHAUST VENT
Warm air exits the monitor through these vents. Ensure that they are not
blocked.
