13

3.5

Resulting Dimensions after Connecting User System Interface Board

The resulting dimensions, after connecting the user system interface board to the user system, are
shown in figures 6, 7, and 8.

24.5

55.0

12.5

68.4

IC socket

(NQPACK176SE manufactured by

User system

Spacer (

φ

6.0)

External bus trace unit

30.0

37.5

27.5

29.2

Unit: mm
Tolerance: ±1.0 mm

24.5

39.19

39.19

24.5

Pin 1

Top view

EV-chip unit

Emulation memory unit

Tokyo Eletech Corporation)

Figure 6 Resulting Dimensions after Connecting User System Interface Board (when

Connecting External Bus Trace Unit, Emulation Memory Unit, and EV-Chip Unit)
