5. Recommended PROM Programmers
The PROM programmers listed in Table 5.1 are recommended for this product. Using the actual
products, we have verified that these PROM programmers can be used to write programs without
problem. Nonconformity occurring by using any other PROM programmers can not be supported.
For the latest type of PROM programmers, contact the manufacturer to confirm whether it can be used
for your product.
Table 5.1 Recommended PROM programmers
MCU type
Programming area
of the MCU
MCU area
Programming area Device name
PROM programmer
M5M27C101
Internal ROM
area
M38B59EFFP
M38B59EFFS
01080
16
- 0FFFD
16
1080
16
- FFFD
16
4.8 Setting a Programming Area
When writing the program into the MCU, be sure to set the programming area. And also, specify its
device of the PROM programmer.
Table 4.2 Programming area
Manufacturer
Advantest
Type name
R4944A
R4945
R4945A
Programming voltage (Vpp)
12.5 V
Device name
M5M27C101 mode
* Be sure to select "Mitsubishi" when specifying the manufacturer for the device.
6. How to Request for Support
After checking this manual, fill in the following information and email to your local distributor.
For prompt response, please specify the following information:
(1) Contact address
• Company name
• Department
• Responsible person
• Phone number
• Fax number
• E-mail address
(2) Product information
• Name of the programming adapter
• Serial number
• Date of purchase
• Target MCU
• Symptoms (Fails blank check/Cannot write a program/Fails verification etc.)
• Detailed symptoms
• How often does the problem occur? (2 out of 10 etc.)
• When did the problem start to occur? (Since purchase/Used to work correctly)
• Type name of the PROM programmer (Advantest R4945A etc.)
• Specified device when writing to PROM (M27C101 etc.)
• Specified programming area when writing to PROM
• Switch settings of the adapter when writing to PROM
