ii
Contents
Section 1 Configuration..................................................................................... 1
Section 2 Environmental Conditions................................................................. 3
Section 3 Connection Procedures ...................................................................... 4
3.1 Connecting User System Interface Board to User System................................................ 4
3.1.1 Installing IC Socket ............................................................................................. 4
3.1.2 Installing Cable Head........................................................................................... 5
3.1.3 Fastening Cable Head .......................................................................................... 5
3.2 Connecting User System Interface Board to EV-Chip Unit ............................................. 7
3.3 Recommended Dimensions for User System Mount Pad (Footprint)............................... 9
3.4 Dimensions for External Bus Trace Unit, EV-Chip Unit, and User System
Interface Board ................................................................................................................. 11
3.5 Resulting Dimensions after Connecting User System Interface Board ............................ 12
Section 4 Installing the MPU to the User System ............................................. 15
Section 5 Verifying Operation........................................................................... 17
Section 6 Notice ................................................................................................ 18
