Specifications

VX-1000d

VX-4000d

VX-5000d

Projector Type:

Digital Light Processing™ (DLP™)

Single SuperOnyx™ DMD™

Digital Light Processing™ (DLP™)

Single SuperOnyx™ DMD™

Digital Light Processing™ (DLP™)

Single SuperOnyx™ DMD™

Native Resolution:

1280 x 720, (16:9)

Aspect Ratios:

Determined by Supplied Processor

Video Standards:

NTSC, PAL

DTV Compatibility:

480p, 720p, 1080i

Picture Size

(16:9 screens)

Recommended Width: 72 – 96 in.

Maximum Width: 200 in.

Recommended Width: 72 – 96 in.

Maximum Width: 200 in.

Recommended Width: 72 – 96 in.

Maximum Width: 200 in.

Throw Distance (Factor x Screen Width)

1.85 to 2.40

Proteus Lens Options:
A: Fixed 0.64 (for rear-screen

applications)

B: Zoom 1.22 – 1.44

C: Zoom 1.45 – 1.76

D: Zoom 1.82 – 2.39 (with CineWide

1.38 – 1.79)

E: Zoom 2.42 – 3.57 (with CineWide

1.84 – 2.70)

F: Zoom 3.63 – 5.72 (with CineWide

2.75 – 4.33)

(Proteus A, B or C options not available with

CineWide or CineWide w/AutoScope)

Telesto Lens Options:
A: Fixed 0.8 (for rear screen

applications)

B: Zoom 1.64 – 1.97

C: Zoom 2.02 – 2.70 (with CineWide

1.53 – 2.04)

D: Zoom 2.84 – 4.80 (with CineWide

2.15 – 3.63)

E: Zoom 4.92 – 7.90 (with CineWide

3.73 – 5.98)

(Telesto A and B options are not available with

CineWide or CineWide w/AutoScope)

Horizontal and Vertical Offset Without

CineWide Option:

(Note: With CineWide option offsets vary per lens.

Please contact Runco Technical Support for more

information.)

Horizontal: 0%

Vertical: 100% (50% of screen height

above and below center)

Horizontal 30% of screen width (15%

left or right of center)

Vertical 100% of screen height (50%

above or below center)

Horizontal 30% of screen width (15%

left or right of center)

Vertical 200% of screen height (100%

above or below center)

Light Output:

CSMS** Specifications:

Home Theater Calibration:

418 – 600 ANSI Lumens†

15.6 – 22.4 Foot-Lamberts (fL)†

1500 ANSI Lumens*

†Variable depending on RVR calibration

CSMS** Specifications:

Home Theater Calibration:

451 – 780 ANSI Lumens†

16.9 – 29.2 Foot-Lamberts (fL)†

1600 ANSI Lumens*

†Variable depending on RVR calibration

CSMS** Specifications:

Home Theater Calibration:

462 – 796 ANSI Lumens†

17.2 – 29.7 Foot-Lamberts (fL)†

1700 ANSI Lumens*

†Variable depending on RVR calibration

Contrast Ratio:

CSMS** Contrast Ratio: 211:1 to 229:1‡

2700:1 to 3300:1‡

‡Variable depending on RVR calibration

CSMS** Contrast Ratio: 220:1 to 237:1‡

3400:1 to 4000:1‡

‡Variable depending on RVR calibration

CSMS** Contrast Ratio: 232:1 to 255:1‡

4400:1 to 5000:1‡;

‡Variable depending on RVR calibration

Lamp:

250W NSH

Lamp Life:

2000 hours

Inputs:

(1) RGB HV, (1) DVI w/HDCP, (1) RS-232 (1) RGB HV, (1) DVI w/HDCP, (1) RS-232 (1) RGB HV, (1) DVI w/HDCP, (1) RS-232

12V Output:

See Controller for Specifications

Power Requirements:

100 – 240V AC, 50/60 Hz, 375W

100 – 240V AC, 50/60 Hz, 380W

Operating Environments:

0° – 95° F, (5° – 35° C),

0% – 90% Humidity (non-condensing)

40° – 95° F, (5° – 35° C),

0% – 90% Humidity (non-condensing)

40° – 95° F, (5° – 35° C),

0% – 90% Humidity (non-condensing)

Dimensions (w/o feet):

Width: 20 7/8 in. (530 mm)

Depth: 21 5/8 in. (550.20 mm)

Height: 7 1/8 in. (181 mm)

with feet 8 1/4 in. (209.50 mm)

Weight: 50 lbs. (23 kg) (includes lens)

Width: 20 7/8 in. (530.2 mm)

Depth: 27 7/8 in. (708.0 mm)

Height: 8 7/8 in. (225.4 mm)

with feet 9 7/8 in. (250.8 mm)

Weight: 73 lbs. (33.1 kg) (without lens)

Width: 20 7/8 in. (530.2 mm)

Depth: 27 7/8 in. (708.0 mm)

Height: 8 7/8 in. (225.4 mm)

with feet 9 7/8 in. (250.8 mm)

Weight: 73 lbs. (33.1 kg) (without lens)

Regulatory Approvals:

Complies with FCC Class B, CE, C-Tick Complies with FCC Class B, CE, C-Tick Complies with FCC Class B, CE, C-Tick

Limited Warranty:

Projector: (2) Two year parts and

labor from the date of delivery to

the end user.

Lamp Warranty: 1000 hours or (6) six

months, which ever comes first.

Projector: (2) Two year parts and

labor from the date of delivery to

the end user.

Lamp Warranty: 1000 hours or (6) six

months, which ever comes first

Projector: (2) Two year parts and

labor from the date of delivery to

the end user.

Lamp Warranty: 1000 hours or (6) six

months, which ever comes first

*ANSI Lumen specification:

This is the typical projector luminosity (brightness) specification

found in most sales literature. This measurement is included

in RUNCO literature to allow for direct comparison with other

manufacturer’s projectors. These measurements can be taken at

9,000 to 13,000º Kelvin to get expected performance data when

the projector is used in professional, commercial, and industrial

displays.
**CSMS Home Theater Calibration ANSI Lumen Specification:

These measurements are taken from the projector as set up in

a home theater environment. The projector is calibrated to ISF

specifications including setting the color temperature to 6500º

Kelvin, the standard for reproducing video.

**CSMS Home Theater Calibration foot-Lambert (fL)

Specification:

This is the unit of measurement used in commercial movie the-

aters to express image brightness. The Society of Motion Picture

and Television Engineers (SMPTE) specifies 16 fL as the target

image brightness for film-based projectors using an open gate

(without film in the projector). More importantly, today SMPTE

specifies 12 fL as the target image brightness in Digital Cinema

theaters using DLP™ technology. The foot-Lambert is dependant

on screen size, screen gain, and projector light output.
All measurements are made at RUNCO to ANSI/NAPM

IT7.228-1997 specifications using the Photo Research PR-650

SpectraColorimeter and Minolta LS-100 Luminance Meter, Video

Essentials test DVD, and a Stewart Filmscreen StudioTech 130,

1.3 gain 72-inch wide screen. The projector is calibrated to a

color temperature of 6500º Kelvin and has a minimum of 150

hours of usage.

Engineered for ISF

calibration.
