DHD Controller SpeCifiCationS
DHD contRolleR
he Reflection portfolio’s VX-1000d, VX-4000d and VX-5000d
projection systems include the DHD controller/processor. the DHD is
engineered with advanced, Vivix ii™ digital video processing to produce stunning
video imagery, even elevating standard ntSc material to near high definition
levels. Superb scaling capabilities output all signals at the 720p native display resolution of the projectors.
the DHD provides for a pure digital signal path from input to output and resides outboard of the projector chassis. this simplifies installation by placing the DHD and
its associated input connections in the equipment rack. only one digital signal cable is then required to the projector. these projection systems can also take full advantage
of Runco’s exclusive livelink™ digital cable solution to preserve HD signal quality and bandwidth over much longer runs than conventional digital signal cables.
Aspect Ratios: Anamorphic, Letterbox, VirtualWide™
4:3 (on either 16:9 or 4:3 screens)
Input Standards: NTSC/PAL
Output Resolution: 720P
Outputs: (1) HD - R (Pr), G (Y), B (Pb), H, V;
(1) DVI w/HDCP
Inputs: (1) Composite; (2) S-Video; (1) Component;
(2) HD - R (Pr), G (Y), B (Pb), H, V;
(2) DVI w/HDCP
Communication
Control Ports:
RS-232 (via DB9 connector),
(1) RJ-11 output (for display only),
IR (with discreet commands),
Front panel controls
Screen Trigger/
Masking Outputs:
(3) 12V DC, 1/8A
Bandwidth: 150 Mega Samples/Second (MSPS)
Power Requirements: 100 – 240V AC (auto sensing)
50/60 Hz, 160W
Operating Environ-
ments:
41°– 95° F, (5° – 35° C),
0% – 90% Humidity (non-condensing)
Dimensions:
(w/out feet)
Width: 17 1/2 in. (444.50 mm),
Depth: 11 3/16 in. (284.10 mm),
Height: 3 3/4 in. (95.25 mm),
Weight: 13 lbs. (5.9 kg)
Included Accessories: Rack mounting brackets
Regulatory Approvals:
Complies with FCC, CE, C-Tick
Limited Warranty: (2) Two years parts and labor from the date
of delivery to the end user
