Chapter 3. Specifications
Tables 3.1 and 3.2 list the specifications of the programming adapters.
Table 3.1 Common specifications of the programming adapters
Table 3.2 Specifications of each programming adapter
Operating clock frequency
4 MHz
(Supplied by the ceramic oscillator mounted on the adapter)
Supplied from Vcc of the PROM programmer
Board to insert a programmable MCU
(IC socket mounted on it)
Interface board
(Connected by two rows of standard-pitch 18-pin connectors
and two rows of standard-pitch 16-pin connectors to the
upper and lower boards)
Board to connect to the PROM programmer
(Standard-pitch 32-pin pin-header mounted)
Board
configuration
Power supply
PCA7402E
PCA7414B
PCA7435FPG02/
PCA7435GPG03/
PCA7435SPG02
PCA7435FPG02
PCA7435GPG03
PCA7435SPG02
Applicable MCU
IC socket
Applicable MCU
IC socket
Applicable MCU
IC socket
Applicable MCU
IC socket
753x Group OTP version
0.8-mm-pitch 36-pin SSOP
(36P2R-A package)
7540 Group OTP version
0.8-mm-pitch 36-pin SSOP
(36P2R-A package)
IC51-0362-309 (made by Yamaichi Electronics Co., Ltd.)
M37531E4/E8FP
M37532E8FP
M37534E8FP
M37540E2/E8FP
7531 Group OTP version
0.8-mm-pitch 32-pin LQFP
(36P6B-A, 32P6U-A package)
7540 Group OTP version
0.8-mm-pitch 32-pin LQFP
(32P6B-A, 32P6U-A package)
M37531E4GP
M37540E2/E8GP
IC51-1498, AC26323 (made by Yamaichi Electronics Co., Ltd.)
7531 Group OTP version
1.778-mm-pitch 32-pin SDIP
(32P4B package)
7540 Group OTP version
1.778-mm-pitch 32-pin SDIP
(32P4B package)
M37531E4/E8SP
M37540E2/E8SP
IC59-3204-G4 (made by Yamaichi Electronics Co., Ltd.)
7536 Group OTP version
1.778-mm-pitch 42-pin SDIP
(42P4B package) M37536E8SP
IC51-4206-G4 (made by Yamaichi Electronics Co., Ltd.)
