1.4 Components
Figure 1.1 shows the HS36024EIO61H expansion I/O board appearance, and table 1.4 lists the
components of the expansion I/O board. Please make sure you have all of these components when
unpacking.
USER
INT
ERFA
CE
CABLE
E6000
EM
ULATOR
E6000
Figure 1.1 HS36024EIO61H Expansion I/O Board
Table 1.4 HS36024EIO61H Components
No. Component Quantity Remarks
1 HS36024EIO61H 1 Expansion I/O board
2 Documentation 1 User’s manual for HS36024EIO61H (this
manual)
