Contents
Section 1 Configuration....................................................................................1
Section 2 Connection Procedures ......................................................................3
2.1
Connecting User System Interface Cable to Emulator Station ......................................... 3
2.2
Connecting User System Interface Cable to User System ................................................ 5 2.2.1
Installing IC Socket ............................................................................................. 5
2.2.2
Inserting Cable Head ........................................................................................... 5
2.2.3
Fastening Cable Body .......................................................................................... 7
2.3
Dimensions for User System Interface Cable Head.......................................................... 8
2.4
Resulting Dimensions after Connecting User System Interface Cable ............................. 9
Section 3 Verifying Operation...........................................................................10
Section 4 Notice ................................................................................................11
