RANGER AUTO – DRIVE SPARE PARTS LIST
ITEM PART No. DESCRIPTION
* COMMON HARDWARE ITEM
1 A10222 Cutterhead Assembly
2 A07195 Spindle Washer
3 A07993 Pulley
4 A12268 V-Belt
5 A07730 Spindle Housing
6 A07755 Swivel Block
7 A07744 Bearing
8 A06359 Cutterhead Spindle
9 A01374 Felt Washer
10 A02304 Spacer Boss
11 A00987 Cutterhead Chute Assembly
12 A07752 Spring Cutterhead Chute
13 A07732 U-Bolt Cutterhead
14 A07733 Washer Plate
15 A07746 Back Plate
16 A07991 C/H Pulley Belt Guide
17 A04006 Pin
18 A10267 Brake Plate Assembly
19 A06124 Brake Pad
20 A02474 Bushes
21 A10221 Brake Rod Assembly
22 A02018 Roll Pin
23 A02227 Brake Pad Rivets
24 A00999 Disc Boss Assembly
25 A00992 Disc Assembly
26
27 A07873 Blade
28 * ⅜” x 1” UNF HT. Hex S/S
29 ─ Available in Kit A00673 Item 30
30 A00673 B.N.W. Set
31 * ¾” UNF Hex Nut
32 A02282 E Retainer
33 * ⅜” UNC Hex Nut
34 ─ Available in Kit A00673 Item 30
35 * ⅜” x ¾” x 16G Flat Washer
36 * ⅜” INT. Shakeproof Washer
37 ─ Available in Kit A00673 Item 30
38 A12106 Warning Label
39
40
41
42
43
44
45
A07597
A02571
*
*
*
A01080
A07989
Key
Warning Label
⅜” x 1¼” UNC Hex Bolt
⅜” UNC Thin Nyloc Nut
⅜” x 1¼” UNC Hex Setscrew
Spring Pin
Spring-Cutterhead Brake Rod
25
