ii
Contents
Section 1 Configuration....................................................................................1
Section 2 Connection Procedures ......................................................................3
2.1 Connecting User System Interface Cable to Emulator Station ......................................... 3
2.2 Connecting User System Interface Cable to User System ................................................ 5
2.2.1
Installing IC Socket ............................................................................................. 5
2.2.2 Soldering IC Socket ............................................................................................. 5
2.2.3 Inserting Cable Head ........................................................................................... 6
2.2.4 Fastening Cable Head .......................................................................................... 6
2.2.5 Fastening Cable Body .......................................................................................... 8
2.3 Recommended Dimensions for User System Mount Pad ................................................. 9
2.4 Dimensions for User System Interface Cable Head.......................................................... 10
2.5 Resulting Dimensions after Connecting User System Interface Cable ............................. 11
Section 3 Installing the MCU to the User System.............................................12
Section 4 Verifying Operation...........................................................................13
Section 5 Notice ................................................................................................14
