CAUTION
When Attaching the Adapter to the PROM Programmer:
• Be careful when attaching to the PROM programmer because incorrect insertion can
cause fatal damage to the MCU.
Figure 4.2 Attaching the adapter to the PROM programmer
4.2 Attaching the Adapter to the PROM Programmer
As shown in Figure 4.2, attach the No. 1 pin of the PCA7402D connector (standard-pitch 28-pin pin-
header mounted) to the No. 1 pin of the IC socket of the PROM programmer.
