HA17458 Series
Rev.1.00 Jun 15, 2005 page 7 of 8
28
24
20
16
12
8
4
0
100 1k 10k 100k 500 5k 50k 500k
V
CC
= +15 V
V
EE
=
−
15 V
Ta = 25 ° C
R
L
= 10 k
Ω
Maximum Output Voltage Swing
vs. Frequency
Maximum Output Voltage Swing Vop-p (V)
Frequency f (Hz)
16
12
8
4
0
−
4
−
8
− 12
−
16
200 1k 10k 500 5k
V
CC
= +15 V
V
EE
=
−
15 V
Ta = 25 ° C
Maximum Output Voltage Swing
vs. Load Resistance
Maximum Output Voltage Swing Vop-p (V)
Load Resistance R
L
(
Ω
)
Voltage Follower Large
Signal Pulse Response
10
0
−
10
0 20 40 60 80
Input and Output Voltage (V)
Time (
µ
s)
Output
Input
V
CC
= +15 V
V
EE
=
−
15 V
R
L
= 2 k
Ω
C
L
= 100 pF
Ta = 25 ° C
