HA17458 Series
Rev.1.00 Jun 15, 2005 page 4 of 8
Characteristic Curves
Input Offset Voltage
vs. Ambient Temperature
5
4
3
2
1
0
Input Offset Voltage V
IO
(mV)
− 20 0 20 40 60 80
Ambient Temperature Ta (
°
C)
V
CC
= + 15 V
V
EE
=
−
15 V
R
S
10 k Ω <
=
Input Bias Current
vs. Ambient Temperature
100
− 20
Ambient Temperature Ta (
°
C)
80
60
40
20
0
Input Bias Current I
IB
(nA)
0 20 40 60 80
V
CC
= + 15 V
V
EE
=
−
15 V
Input Offset Current
vs. Ambient Temperature
20
Input Offset Current I
IO
(nA)
− 20
Ambient Temperature Ta (
°
C)
16
12
8
4
0
0 20 40 60 80
V
CC
= + 15 V
V
EE
=
−
15 V
Power Dissipation
vs. Ambient Temperature
200
− 20
Ambient Temperature Ta (
°
C)
Power Dissipation Pd (mW)
0 20 40 60 80
100
0
V
CC
= + 15 V
V
EE
=
−
15 V
No Load
Both Amplifiers
