9
The model number will be found on a plate attached to the motor housing. Always mention the
model number in all correspondence regarding your
MITER SAW or when ordering repair parts.
MS1250LZA
PARTS LIST FOR FIGURE D
Key Part
No. Number Description Qty.
1 81449-1 LOCK NUT (M x 1.0 mm) ...........................2
2 820238-5 WASHER......................................................1
3 823340-1 ACTUATOR LINK .........................................1
4 82025-01 SPACER ( x 10 x 4) ....................................1
5 82032-2 WASHER......................................................1
8289 GUARD RETAINER ......................................1
830530 LOWER GUARD ..........................................1
8 81 GUARD SPRING ..........................................1
9 82183 SCREW (10-32 x .50, SHOULDER) .............1
10 830529 LOWER GUARD PIVOT ...............................1
11 828141 WASHER......................................................1
12 020123008 SCREW (10-32 x 1/2 in., PAN HD)...............1
13 82409 BEARING RETAINER ...................................1
14 828142 SCREW (M x 1.0-13 mm, FLAT HD) ..........1
15 82032-1 WASHER......................................................1
1 82024-01 SCREW (M5 x 0.8-1 mm, SHOULDER) .....1
1 822001 NO HANDS WARNING LABEL ....................1
