The model number will be found on a plate attached to the motor housing. Always mention the
model number in all correspondence regarding your
MITER SAW or when ordering repair parts.
MS1250LZA
PARTS LIST FOR FIGURE C
Key Part
No. Number Description Qty.
1 08910020003 BLADE SCREW ...........................................1
2 830523 BLADE WASHER .........................................1
3 830524 BLADE COLLAR (OUTER) ...........................1
4 828042 BLADE .........................................................1
5 83052 BLADE COLLAR (INNER) ............................1
8288-2 SCREW W/ WASHER (M8-35, PAN HD) ......4
82188 SCREW (10-32 x /8 in., SHOULDER) ........1
8 82498 RUBBER SLEEVE ........................................1
9 82512 ARBOR LOCK..............................................1
10 8251 GRIP CAP ....................................................1
11 823402 SPRING .......................................................1
12 830531 UPPER ARM GUARD ..................................1
13 823353 ARBOR LOCK PLATE ..................................1
14 823404 SCREW (M5 x 0.8-8 mm) ............................2
15 823359 ARBOR LOCK GROMMET ..........................1
1 828045 DUST BAG ...................................................1
1 828038 ELBOW ........................................................1
18 828040-1 SCREW (M x 1.0-1 mm, SET LOCK) .......1
19 82543 SAWDUST CHUTE ......................................1
20 828119 SCREW (M5 x 0.8-25 mm) ..........................1
21 8155- SCREW (M5 x 0.8-1 mm, PAN HD) ...........1
22 82330 LOWER GUARD BUMPER ..........................1
23 820238-2 WASHER......................................................1
24 82182 BEARING GUIDE .........................................1
25 82185-1 SCREW (M x 14 mm SHOULDER) ............1
2 08910030024 LASER .........................................................1
2 08910030031 ADJUSTABLE LASER BOLT ........................1
28 82102 WARNING LABEL (UPPER GUARD) ...........1
29 0891003002 WARNING LABEL ........................................1
30 0891003002 1/1 in. HEX KEY .........................................1
31 08910030020 ADJUSTABLE LASER KIT
(INC. KEY NOS. 2-2 AND 29-30) .............1
