RIDGID MS1250LZA - Manual (Page 11)

11
The model number will be found on a plate attached to the motor housing. Always mention the
model number in all correspondence regarding your
MITER SAW or when ordering repair parts.
MS1250LZA
PARTS LIST FOR FIGURE E
Key Part
No. Number Description Qty.
1 8280 TORSION SPRING ......................................1
2 823320 TORSION SPRING SPACER .......................1
3 823344 PIVOT SHAFT ARM .....................................1
4 828034 RUBBER CAP ..............................................1
5 821421-2 O-RING ........................................................1
828035 LOCKING PIN ..............................................1
82810-1 PIVOT ..........................................................1
8 828120 SCREW (M4 x 0.-5 mm, SET LOCK) .........1
9 82103-1 WASHER......................................................1
10 82811 WASHER......................................................1
11 81919 WASHER SPRING .......................................1
12 8185 LOCK NUT (M12) .........................................1
13 82488 BEVEL KNOB ..............................................1
14 82810 WASHER......................................................1
15 82185-4 SHOULDER SCREW (M x 23 mm) ............1
1 82342-2 BALL (5 mm) ................................................1
1 828039 SPRING .......................................................1
18 828040 SCREW (M x 1.0-10 mm, SET LOCK) .......1
19 828041-1 BEVEL INDEX PIN .......................................1
20 08910030028 INSTRUCTION SHEET (NOT SHOWN)........1
21 08910030029 CARD (NOT SHOWN) ..................................1
9800001 OPERATOR'S MANUAL
5-10-0
(REV:01)
