Appendix A: Specifications 83
Appendix A: Specifications
General
Size (H x W x D) 3.11” (79 mm) x 6.57” (167 mm) x 6.73” (171mm)
Weight 2.87 lbs (1.3kg)
Mounting Bracket or flush mount
Power 13.6 VDC ±15%
Environmental:
Operating Range:
Storage Range:
Humidity:
Waterproof to IPX7
–15°C to +55°C
–20°C to +70°C
up to 95%
Frequency Range:
Transmit
Receive 156.050 To 157.425 MHz
156.050 To 163.275 MHz
Channels All available US, Canadian and International VHF Marine
Band.
Oscillate Mode PLL
Modulation FM(16K0G3E)
DSC(16K0G2B)
Channel Spacing 25 kHz Increments
Frequency Stability +/- 10PPM (+/- 0.001%)
