Raypak XFYRE 500 - Manual (Page 8)

ASME Section IV, National Board Registered, 160 PSI • H Stamp v v
Heat Exchanger Tubes • 316L Stainless Steel v v
Stainless Steel • CSA Verified AB-1953 CA low lead compliant v v
Pressure Relief Valve • 60 PSI V v
(loose) • 125 PSI v V
• 30, 45, 75, 150 PSI V V
Temperature & Pressure Gauge (Loose) v v
Pump • 120V, Single-Phase V V
Indoor/Outdoor Certified v v
Vent Terminal • Outdoor V V
• Through-the-Wall V V
Fully-Enclosed Controls v v
Combustible Floor Rated v v
120V Power Supply v v
On/Off Switch v v
Programmable Pump Time Delay, Single-Phase • Included in Controller v v
Terminal Block Connections • Enable / Disable v v
(Front mounted) • 0-10 VDC Setpoint/Direct Drive Input v v
LCD diagnostic display with 10-Event History (2x20 character display, reads in plain English) v v
Temperature Controller with 3 Water Sensors • (up to 5:1 Turndown) v v
• Outdoor Reset Sensor N/A V
Multiple Boiler Controller • TempTracker Mod+ Hybrid, up to 16 boilers/groups V V
Direct Spark Ignition System • 1-try V V
• 4-try v v
High/Low Gas Pressure Switches V V
Blocked Vent Switch v v
High Limit Switch • Manual Reset, Fixed v v
• Automatic Reset, Fixed V V
Low Water Cut-Off, 24V • With Manual Reset and Test Buttons V V
Flow Switch v v
Modulating Combination Gas Valve v v
Combustion Air Blower v v
Additional Safety Valve • Motorized (externally mounted) V V
• Solenoid (externally mounted) V V
CSA-Certified Efficiency • 94% at Full Fire N/A v
• 95% at Full Fire v N/A
• 99% at Part Load v v
Air Filter v v
TruSeal Direct-Vent V V
Alarm Contacts v v
CSD-1 / GE GAP Control System V V
Low NOx • Meets all current requirements v v
Condensate Drain and Trap v v
Condensate Neutralizer V V
Water
Heaters
(Type WH)
Boilers
(Type H)
v v = Standard V V = Optional
Raypak, Inc. • 2151 Eastman Avenue, Oxnard, CA 93030 • phone: (805) 278-5300 • fax: (800) 872-8725 • www.raypak.com
© 2009-2010 Raypak, Inc. Cat. No. 1000.22B Effective: 07-15-10 Replaces: 02-15-10
