Secure the backplate onto the
motherboard by using the four
collars nuts . Turn these
down onto the insulation washer,
do not tighten one first, work
around all four, gradually
tightening them all.
8
user manual COOLER RCX-Z4
Put the four rubber pads on
top of the four screws .
Place the insulation washer
over the screws so they sit on the
motherboard as shown. Follow the
same procedure for all four screws.
7
8
9
B
G
G
A
