Place the cooler onto the four
screws, secure the cooler with
four more collars .
9
user manual COOLER RCX-Z4
Screw the fan onto the heatsink
using the four black screws.
Apply the proper amount of
thermal compound on the CPU
surface, a thin film is ideal, extra
thermal compound will not
improve performance.
Make sure the CPU surface is
perfectly clean.
10
11
12
G
H
See page 10-11 for the backplate fan
controller and fan Installation
The RCX-Z4 is now installed on your INTEL LGA 775 CPU
