General Information
Quantity of
Vent Size
(in.)
Model
No.
Burners
Gas
Valves
Blowers Flue Intake
992A
11
2 + 1*
2
10
10
1262A
14
3 + 1*
2
12
10
1532A
17
4
2
12
10
1802A
20
4
2
14
10
2002A
23
5
3
14
10
2072A
23
5
3
14
10
2342A
26
5
3
16
10
* Hidden solenoid located inside of air plenum.
Burners per Valve
Stages
% Fire at Stage
Model
No.
1
1A
2
3
4
1
2
3
4
1
2
3
4
992A
6
3
2
1
1, 2
1, 2, 3
54
82 100
1262A
5
3
3
3
1
1,2
1, 2, 3
1, 2, 3, 4
36
57 79 100
1532A
6
4
4
3
1
1,2
1, 2, 3
1, 2, 3, 4
35
59 82 100
1802A
6
4
5
5
1
1,2
1, 2, 3
1, 2, 3, 4
30
50 75 100
2002A
4
5
5
5
4
1, 1A 1, 1A, 2
1, 1A, 2, 3 1, 1A, 2, 3, 4 40
63 86 100
2072A
4
5
5
5
4
1, 1A 1, 1A, 2
1, 1A, 2, 3 1, 1A, 2, 3, 4 40
63 86 100
2342A
5
6
5
5
5
1, 1A 1, 1A, 2
1, 1A, 2, 3 1, 1A, 2, 3, 4 42
62 81 100
Table A: Basic Data
Table B: Manifold Data
