9.In s t a l ling t he b ob b i n c a s e(Fig . 7 )
1.Open the hook cover,put the bobbin and bobbin
Case into the hook;
2.put the bobbin case on the hook driving shaft,then
lay down the hook cover.
10.W i n d i ng t he b obbi n t h r e a d(Fig . 8 )
1.T hre ad as fol low ing ord er A,B ,C, the n win d the thr ead
aro und bob bin sev era l cir cle s;
2.P res s dow n the bob bin pre ss pla te
,th e win din g
pul ley wil l be tou che d wit h the V-b elt ;
3.w ind ng amo unt can be adj ust ed by the scr ew
,th e
opt imu m cap aci ty of bob bin thr ead is fil l abo ut 80%
of bob bin out sid e dia met er. Tur n the scr ew clo ckw ise
to inc rea se the win din g amo unt ,co ntr ary ,to dec rea se
the amo unt ;
4.I f the thr ead is not nea t,p lea se mov e the bra cke t
to adj ust is;
5.W hen the win din g is ove r, the bob bin pre ss pla te
wil l be loo se and the bob bin win der wil l sto p aut oma -
tic all y.
①
②
③
①
11.P u t t h e b o b bin i nto b obb i n c a s e (fig. 9 )
1.Draw the tip of bobbin thread to the right ,then put the
bobbin into bobbin case;
2.Draw the bobbin thread through the slit
on the
bobbin case,then pass through the thread tension
spring,finally,draw the thread out of the slit
.
Reminder:if the bobbin is put correctly,then draw the
bobbin thread as A,the bobbin will rotates as B.
①
②
A
B
C
①
②
③
①
②
B
A
