Page 2

3.Op e r a t ion p repa r a t ion
1.Br i e f i n t roduct i o n
1 . M ain s peci f i c a tion
T h i s c y l i n d e r b e d s e w i n g m a c h i n e a d o p t s s i n g l e
n e e d l e , s l i d e t y p e t h r e a d t a k e - u p l e v e r , a n d v e r t i c a l l a r g e
h o k . U p p e r a n d l o w e r s h a f t s a r e d r i v e n b y s y n c h r o n i z e d
t o o t h e d b e l t . C o m p o u n d f e e d b y f e e d d o g , n e e d l e a n d
walking foot;and high presser foot stroke and lifter assure
its high sweing heavy ability and easy for sewing multi-
l a y e r l e a t h e r a n d u n e v e n m a t e r i a l s . S a f e t y c l u t c h d e v i c e
also assures safe operation .
I t s w i d e l y u s e d f o r s e w i n g l e a t h e r p r o d u c t s , s u i t c a s e s ,
shoes ad caps.Especially,its cylinder bed is suitable for
sewing various arc and curved materials. .
2000s.p.m
MSK- 1341B
6m m
33 .3 6m m
6. 5m m b y ha nd
15 mm by k ne e
Sl id e t y pe
La rg e h o ok
Dp×17 14"~24"(standard23")
Oi le d b y ha nd
400W(special for sewing machine 2P)
Me di um ,h ea vy , ex tr a h ea v y
we ig ht m at er ia l s
Befre first operate the machine,please clean the machine thoroughly in order to weed out the
dust and frlly lubricate the machine.
Please confirm if the power will be used is suitable for the designed voltage.
The rotating direction of the machine is counter-clock wise when observed face to the hand wheel.
Before turn over the machine head,please take down the knee lifter chain hook.
Before trial running,please take down the bobbin and needle.
Please control the sewing speed under 1800s.p.m within the first operation month.
Only after the machine stops,then the hand wheel can be operated.
4.In s t a l ling t he k ne e l i f t e r m echani s m ( Fig.1)
When use the knee lifter pedal,please use the screw
to fix the knee lifter lever .
Knee lifter leaver and screw are packed in the ac-
cessory carton.
272mm
61mm
100.5mm
33.5mm
①
②
Max.sewing speed
Max.stitch length
Needle bar stroke
Presserfoot lift
height
Thread take-up lever
Hook
Needle
Lubrication
Motor Power
Abblication
To center of V-belt
