Preparation

Notes:

• If you did not install a backup battery,

, and

alternately appear.

• Do not press any of the system’s buttons while you are

plugging the adapter into the AC outlet. If you accidentally
press a button, reset the system by unplugging the adapter
from the AC outlet and re-inserting it.

• The system cannot operate without AC power.

CONNECTING THE SYSTEM TO A PHONE
LINE

Plug the system’s attached phone line cord into the wall jack.
Plug the modular phone line cord into the system’s

TEL LINE

jack.

Attached Phone Line Cord

Wall
Jack

DC 9V Jack

Modular Phone
Line Cord

AC Power Cord

TEL LINE Jack
