ROTEL RC-06 - Manual (Page 9)

9 English
Specifi cations
Total Harmonic Distortion (20 Hz-20 kHz) < 0.004%
Intermodulation Distortion (60 Hz : 7 kHz, 4:1) < 0.004% at 1V output
Frequency Response
Phono Input (MM) 20Hz-20kHz, ±0.5dB
Line Level Inputs 4Hz-100kHz, ±3dB
Input Sensitivity / Impedance
Phono Input (MM) 1.2mV / 68 kOhms
Line Level Inputs 150 mV / 24 kOhms
Input Overload
Phono Input (MM) 160mV
Line Level Inputs 5V
Output Level / Impedance 1 V/ 100 Ohms
Usable Headphone Impedance 8 - 2,000 Ohms
Signal to Noise Ratio (IHF “A” weighted)
Phono Input (MM) 70 dB
Line Level Inputs 100 dB
Power Requirements
USA
Version 120 Volts, 60 Hz
European Version 230 Volt, 50 Hz
Power Consumption 10 Watts
Dimensions (W x H x D) 437 x 72 x 328 mm
17 1 /
8
x 2 7 /
8
x 12 15 /
16
”
Front Panel Height 60mm
Weight (net) 4.3 kg, 9.5 lbs.
All specifications are accurate at the time of printing.
Rotel reserves the right to make improvements without notice.
12 Volt Trigger Outlet
t
Some audio components can be turned on
automatically when they receive a 12V turn
on “signal”. The 12V Trigger Outputs of the
RC-06 provide the required signal. Connect
compatible components to the RC-06 with a
conventional 3.5mm miniplug cable. When the
RC-06 is in Standby mode, the trigger signal
is interupted, so the components controlled by
it are turned off.
Troubleshooting
Most diffi culties in audio systems are the result
of incorrect connections, or improper control
settings. If you encounter problems, isolate the
area of the diffi culty, check the control settings,
determine the cause of the fault and make the
necessary changes. If you are unable to get
sound from the RC-06 refer to the suggestions
for the following conditions:
Power Indicator Is Not Lit
The Power Indicator should be lit whenever the
RC-06 is plugged into the wall power outlet. If it
does not light, test the power outlet with another
electrical device, such as a lamp. Be sure the
power outlet being used is not controlled by
a switch that has been turned off.
Fuse Replacement
If another electrical device works when plugged
into the power outlet, but the Power Indicator
of the RC-06 does not light when plugged into
the same outlet and the Power Switch is pushed
in, it indicates that the internal power fuse may
have blown. If you believe this has happened,
contact your authorized Rotel dealer to get the
fuse replaced.
No Sound
Check the signal source to see if it is function-
ing properly. Make sure the cables from the
signal source to the RC-06 inputs are con-
nected properly. Be sure the Function Control
and Monitor Control are properly set. Check
the wiring between the RC-06 and the power
amplifi er. Be sure the power amplifi er is on
and the speakers are properly connected. If
the power amplifi er has level controls be sure
they are set properly.
