2.Installation
2-1.Connecting the U2SCXU to a SCSI device
Terminator
The fig.1 shows how to connect a terminator and
the U2SCXU when you connect only one SCSI
device.
The fig.2 shows how to connect a terminator and
SCSI cable and the U2SCXU when you connect
daisy-chain SCSI devices.
Terminator
This chapter explains how to connect a SCSI device to the U2SCXU.
Follow the steps through to connect your SCSI device to the U2SCXU:
Fig. 2
Fig. 1
