6. Precautions
CAUTION
Cautions to Be Taken for This Product:
z Before mounting the M38C29T-64LCA, be sure to check the pin positions.
IMPORTANT
Notes on This Product:
z We cannot accept any request for repair.
z For inquiries about the product or the contents of this manual, contact your local distributor.
Renesas Tools Homepage http://www.renesas.com/tools
7. Correspondence of the Connectors
Table 2 Correspondence of connectors J1 and J2
J1 connector
Pin No.
J2 connector
Pin No.
J1 connector
Pin No.
J2 connector
Pin No.
J1 connector
Pin No.
J2 connector
Pin No.
J1 connector
Pin No.
J2 connector
Pin No.
1 - 26 - 51 - 76 -
2 - 27 - 52 - 77 -
3 - 28 - 53 - 78 -
4 - 29 - 54 - 79 -
5 - 30 - 55 - 80 -
6 - 31 - 56 - 81 -
7 - 32 - 57 - 82 -
8 49 33 1 58 17 83 33
9 50 34 2 59 18 84 34
10 51 35 3 60 19 85 35
11 52 36 4 61 20 86 36
12 53 37 5 62 21 87 37
13 54 38 6 63 22 88 38
14 55 39 7 64 23 89 39
15 56 40 - 65 24 90 40
16 57 41 8 66 25 91 41
17 58 42 9 67 26 92 42
18 59 43 10 68 27 93 43
19 60 44 11 69 28 94 44
20 61 45 12 70 29 95 45
21 62 46 13 71 30 96 46
22 63 47 14 72 31 97 47
23 64 48 15 73 32 98 48
24 - 49 16 74 - 99 -
25 - 50 - 75 - 100 -
("-": No connection)
