7
User Manual
SATA II / ATA 133 PCIe Card RC216
Rebuild Mirror Drive
When a failure to one member occurs, you will be notified by the RAID BIOS during boot. The
steps below will guide you in rebuilding a failed mirror set.
1. Replace he failed drive(s) with one of equal or greater capacity, then start the computer.
2. During boot press
Ctrl+J to enter the RAID BIOS.
3. Select
Rebuild Mirror Drive press Enter.
4. Please use arrow keys
↑ and ↓ to select the array you want to rebuild, press Enter.
5. Please use arrow keys
↑ and ↓ to select the destination disk, press Enter.
6. When rebuilding is finished, select
Save And Exit Setup, press Enter.. When asked Save to
disk &Exit (Y/N)?, press Y to exit the BIOS.
BIOS Configuration
The PCIe SATA II 300 + PATA Raid Card BIOS will appear every time your system starts up.
During this (POST) process, the BIOS will show up and indicate the devices attached to it.
Driver Installation
For Windows® 2000, XP and Server 2003 32bit
For New Installation
A new installation requires a floppy disk for the driver installation. To make this floppy disk, copy
the contents of the “
RC-216\Floppy32” folder, found on the driver CD, onto a blank floppy disk
then follow the directions below.
1. Setup the RAID Array prior to Windows installation.
2. Follow Microsoft’s Windows installation procedure.
3. Restart the computer when prompted by Windows’ installation.
4. At the Windows Setup screen, press
F6 to install the RAID driver.
5. When prompted, press
S to specify the location of the driver.
6. Insert the floppy disk, then press
Enter.
7. Select
(Windows 2000) RAID Driver for JMicron JMB363 Controller or (Windows XP/2003)
RAID/AHCI Driver for JMicron JMB36X Controller, then press Enter.
8. Press
Enter to finish driver installation, then follow the on-screen instructions to complete the
Windows installation.
