Introduction
This Wet/Dry Vac is intended for house-
hold use.
IMPORTANT NOTE
Please Read Carefully
Static Shocks Are Common - In dry
areas or when the relative humidity of the
air is low. To reduce the frequency of
static shocks in your home the best rem-
edy is to add moisture to the air with a
console humidifier.
Unpacking and Checking Carton Contents
Remove entire contents of carton. Check
each item against the Carton Contents
List. Call 1-800-4-RIDGID or E-mail us at
[email protected] if any parts
are damaged or missing.
Carton Contents List
Key Description .............................. Qty
.
A Vac Assembly .............................. 1
B Hose Assembly.............................1
C Extension Wands.........................2
D Filter Cage ................................... 1
E Filter............................................. 1
F Float............................................. 1
G Filter Nut ......................................1
H Utility Nozzle ................................ 1
J Caster Foot w/Storage (WD1230) 2
(WD1200) ....................................4
K Caster Foot (WD1230 only)......... 2
L Caster Twin Wheel....................... 4
M Wet Nozzle (WD1200 only) ......... 1
N Car Nozzle (WD1200 only)...........1
O Hose Lock (WD1200 only)........... 1
P Owners Manual ............................1
Caster/Caster Foot Assembly
1. Turn the dust drum upside down on the
floor.
2. Insert the caster feet into the bottom of
drum, as shown (4 places).
3. Push on the caster foot until the foot is
NOTE: Position storage casters at desired
location.
flush with bottom of the dust drum.
4. Insert the caster stem into the socket of
the caster foot, as shown (4 places).
5. Push on the caster until the ball on the
caster stem is inserted all the way into
the socket. You will hear the ball snap
into the socket and the caster will swivel
easily when positioning is correct.
6. Turn the drum upright.
A
B
C
D
E
F
G
H
J
K
L
P
Caster
Caster Stem
Caster Ball
Pin
Caster
Foot
Hole
Dust Drum
M
N
O
