12
Repair Parts
12 U.S. /10 CDN. Gallons Wet/Dry Vac
Model Number WD12001 or WD12300
RIDGID parts are available on-line at www.ridgidparts.com
Always order by Part Number - Not by Key Number
WARNING
SERVICING OF DOUBLE-INSULATED WET/DRY VAC
In a double-insulated Wet/Dry Vac, two systems of insulation are provided
instead of grounding. No grounding means is provided on a double-insulated
appliance, nor should a means for grounding be added. Servicing a double-
insulated Wet/Dry Vac requires extreme care and knowledge of the system,
and should be done only by qualified service personnel. Replacement parts
for a double-insulated Wet/Dry Vac must be identical to the parts they replace.
Your double-insulated Wet/Dry Vac is marked with the words “DOUBLE INSU-
LATED” and the symbol
(square within a square) may also be marked on
the appliances.
* Standard Hardware Item - May Be Purchased Locally
† These replacement parts are available where you purchased your vac.
Key
No. Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
21
22
23
24
29
73180
823684-5
824967
822467-7
*
823685-4
818793
818961
818413-2
15534-1
73352
823683-6
509488
823201-1
VF4000
73316
826314
825881-2
818231
822481
VT2509
VT2508
VT2507
SP6407
Toggle Switch
Motor Cover
Motor (Includes Blower Wheel)
Cord w/plug
Screw, Pan Hd. Ty “AB” 10x3/4
Collector
Lid Gasket
Spacer
Blower Wheel
Washer
Nut, Hex Flange 1/4-20
Lid
Float
Filter Cage
† Filter
Filter Nut
Dust Drum
Drain Cap
Caster Foot w/Storage
Caster Twin Wheel
20 73164 Caster Foot (WD1230 only)
† Utility Nozzle
† Extension Wand
† Hose
25 VT2503 † Car Nozzle (WD1200 only)
26 VT2510 † Wet Nozzle (WD1200 only)
27 822256 Squeegee (WD1200 only)
28 818230-1 Hose Lock (WD1200 only)
Owners Manual
806742-5
