5. Specifications

Applicable compact emulator

M30850T3-CPE

Size of emulation memory installed

4Mbytes

Applicable MCU mode

Memory expansion mode, Microprocessor mode

Applicable power supply

3.0 to 5.5 V

Maximum operating frequency

1Ш+1Ш : 32MHz*

Emulation memory allocation

Memory expansion mode: Maximum 3.25Mbytes
Microprocessor mode: Maximum 4.00Mbytes

*The restrictions in this product operating frequency depend on VCC2 power voltage.
(These restrictions only need to be observed when using an emulator.) (See Figure 2)

Intelligent I/O 1wait read access

3.0

Operating
frequency

[MHz]

0

24

5.5

VCC2

voltage[V]

Intelligent I/O 2wait (set the PM13 bit to "1") read access

3.0

0

24

32

4.2

Operating

frequency

[MHz]

5.5

VCC2

voltage[V]

Figure 2 Restrictions in operating frequency when using this product
(When using in single-power supply: VCC1 = VCC2, When using in dual-power supply: VCC1 = 5.0 ± 0.2 [V] fixed)

6. Precautions

WARNING

Warnings to Be Taken for This Product:

z Do not disassemble or modify this product. Personal injury due to electric shock may occur if this product is

disassembled and modified. Disassembling and modifying the product will void your warranty.

Warning for Installation:

z Do not set this product in water or areas of high humidity. Make sure that the product does not get wet. Spilling

water or some other liquid into the product may cause unrepairable damage.

Warning for Use Environment:

z This equipment is to be used in an environment with a maximum ambient temperature of 35°C. Care should be taken

that this temperature is not exceeded.

CAUTION

Cautions to Be Taken for This Product:

z Use caution when handling this product. Be careful not to apply a mechanical shock.
z Do not touch the connector pins of this product directly. Static electricity may damage the internal circuits.

Caution to Be Taken for System Malfunctions:

z If the emulator malfunctions because of interference like external noise, do the following to remedy the trouble.

(1) Press the RESET button on the emulator upper panel.
(2) If normal operation is not restored after step (1), shut OFF the emulator once and then reactivate it.

Caution to Be Taken for Using with M30850T2-CPE and M30870T2-CPE:

z Do not use this product with M30850T2-CPE and M30870T2-CPE.

7. Inquiries


For inquiries about this product or the contents of this manual, contact your local distributor.
Renesas Tools Homepage http://www.renesas.com/tools

(4/4)
