2
CAUTION
Use a NQPACK100SD-ND socket (manufactured by Tokyo
Eletech Corporation) and a HQPACK100SD (manufactured by
Tokyo Eletech Corporation) for the PTQP0100KA-A (former
code: TFP-100BV) package IC socket and socket cover,
respectively, on the user system.
Table 1 R0E570830CFK00 Components
No. Component Quantity Remarks
1 Board 1 With four spacers (2.6MP x 11 mm)
2 IC socket 1 For the PTQP0100KA-A (former code:
TFP-100BV) package (to be mounted on the user
system)
3 Socket cover 1 For the PTQP0100KA-A (former code:
TFP-100BV) package (for installing MCU)
4 Screws (M2.0 x 10 mm) 4 For fastening board
5 Screws (M2.0 x 6 mm) 4 For installing a PTQP0100KA-A (former code:
TFP-100BV)-packaged MCU
6 Guide pins 3
7 Screwdriver 1
8 User’s manual 1 User’s manual for R0E570830CFK00 (this
manual)
