1. Description
M3T-64DIP-DMS is a conver ter board to connect the
64-pin RSS type emulator MCU to the DUMMY64
( not included). Using the DUMMY64, the
M3T-64DIP-DMS converts the pin assignments
of an emulator MCU for the 64-pin 0.8mm pitch QFP.
2. Package Components
(see Figure 1)
(1) 64DIP-DMS conver ter board
Figure 1 Package components of M3T-64DIP-DMS
M3T-64DIP-DMS main unit
(2/4)
P
(64-pin 0.8mm pitch QFP)
4. Application
(see Figure 2)
Mount DUMMY64 on the QFP socket on the target, then
connect
it to the probe of the emulation pod.
Figure 2 Usage of M3T-64DIP-DMS
3. Specifications
Table 1 Specifications
Item Description
Package
: position of No. 1 pin
Be sure to match the position of
No. 1 pin of the foot pattern and
each pin.
(2) 64DIP-DMS User's Manual (this manual)
5. Connection Procedure
(see Figure 2)
(1) Mount the socket on the target.
(4) Mount an emulator MCU on the 64DIP-DMS.
(2) Mount the DUMMY64 on the socket.
(3) Attach the socket frame to the socket.
Foot pattern
Socket
Socket frame
DUMMY64 main unit
6 4 DIP-DMS
Emulator MCU
M38000TL2-FPD
(1)
(2)
(3)
Insertion/removal
iterations of connector
20 times guaranteed
(6) Connect the M3T-64DIP-DMS to the DUMMY64.
(5) Connect the M38000TL2-FPD to the 64DIP-DMS.
(6)
(4)
(5)
To mount QFP socket
* Be sure to prepare a foot pattern for holding
devices (4 corners) to solder the socket.
64D0
(64-pin 0.8mm pitch QFN)
PRQP0064GA-A (formerly: 64P6N-A)
