PC7501 Setup Guide
For details, refer to...
1
Check the contents.
>> PC7501 Packing List (Back)
2
Register your PC7501.
>> PC7501 User Registration Tool (Start up the REG7501E.EXE in the \REGISTER\ENGLISH folder on the Renesas Debugger
Package CD-ROM) or send a hardware tool user registration FAX sheet
3
Install an emulator debugger.
>> README.HTM on the Renesas Debugger Package CD-ROM
Download the latest emulator debugger from http://www.renesas.com/en/tools
4
Setup hardware.
>> PC7501 User’s Manual “Chapter 4 Setup (P.23)” and the user’s manual of the emulation probe
For Troubleshooting... PC7501 User’s Manual “5.2 Interface Connection Error (P.37)”
5
Turn on the PC7501 in maintenance mode.
>> PC7501 User’s Manual “4.4 Downloading Firmware (P.34)”
6
Start up the emulator debugger.
>> Emulator Debugger User’s Manual (Online Help)
7
Make settings for the emulator debugger.
>> Emulator Debugger User’s Manual (Online Help)
8
Download firmware.
>> PC7501 User’s Manual “4.4 Downloading Firmware (P.34)” and Emulator Debugger User’s Manual (Online Help)
For Troubleshooting... PC7501 User’s Manual “5.3 Firmware Download Error (P.39)”
9
Exit the emulator debugger, and turn off the PC7501.
10 Execute the self-check.
>> User’s Manual of each emulation probe
11 Start up the emulator debugger.
>> Emulator Debugger User’s Manual (Online Help)
For Troubleshooting...
PC7501 >> PC7501 User’s Manual “Chapter 5 Troubleshooting (P.37)”
Emulator debugger >> Emulator Debugger User’s Manual (Online Help)
Renesas Tool Homepage PC7501 Emulators Site >> http://www.renesas.com/eng/products/mpumcu/toolhp/pc7501/
© 2005. Renesas Technology Corp. and Renesas Solutions Corp., All rights reserved. Printed in Japan.
Rev.1.00
05.03.01
REJ10J0902-0100T
