6
Table 3 Setting a Switch (SW1)
Switch
Setting
SW1
No. PLQP0112JA-A
(Former Code:
FP-112EV)
Socket Pin No.
Signal Name
On
Off
1 51 PA0/_CS4/RXD0 Mask canceled Mask enabled
2 50 PA1/_CS5/TXD0 Mask canceled Mask enabled
3 45 PA6/_CS2/TCLKA Mask canceled Mask enabled
4 44 PA7/_CS3/TCLKB Mask canceled Mask enabled
5 41 PA10/_CS0/_POE4 Mask canceled Mask enabled
6 40 PA11/_CS1/_POE5 Mask canceled Mask enabled
Table 4 Setting a Switch (SW2)
Switch Setting
SW2
No. PLQP0112JA-A
(Former Code:
FP-112EV)
Socket Pin No.
Signal Name
On
Off
1 30 PB7/A19/_BREQ/IRQ5/TXD0 Mask canceled Mask enabled
2 31 PB8/A20/_WAIT/IRQ6/SCK0 Mask canceled Mask enabled
3 79 PA17/_WAIT Mask canceled Mask enabled
4 102 PE5/_CS6/TIOC1B/TXD3 Mask canceled Mask enabled
5 104 PE6/_CS7/TIOC2A/SCK3 Mask canceled Mask enabled
6 - Unused - -
