Item
MCU type
Operating clock frequency
Power supply
IC socket
3. SPECIFICATIONS
Table 3.1 lists specifications of the PCA7414.
Table 3.1 Specifications of PCA7414
PCA7414
PCA7414B
PCA7402D
Description
M34551E8FP
1 MHz
(Supplied by the ceramic oscillator mounted on the PCA7414)
Supplied from Vcc of the PROM programmer
IC51-0484-652 (Made by Yamaichi Electronics Co., Ltd.)
Board to insert the programmable MCU
(IC socket for 48-pin QFP is mounted.)
Interface board
(Connected by two standard pitch 18-pin connectors and two standard
pitch 16-pin connectors to the upper and lower boards)
Board to be connected to the PROM programmer
(Standard pitch 28-pin pin-header to be connected to the PROM pro-
grammer is mounted.)
Board
configuration
